Nitrous Oxide Cylinder Valve, CGA 910, MRI Compatible KVMB91051-32, O-Ring Included

Name: Nitrous Oxide Cylinder Valve, CGA 910, MRI Compatible KVMB91051-32, O-Ring Included
Brand: Sherwood
SKU: KVMC91051-32R
Price: 104.69 USD
Availability: InStock

SKU

KVMC91051-32R

Sherwood non-magnetic CGA 910 nitrous oxide valve, .750-16 UNF-2A inlet thread with 3360 PSI CG-1 PRD. Shipped with PTFE o-ring installed. MRI compatible (magnetic resonance environment) with TS markings.

Download Technical Sheet

Product Information

Chrome plated brass non-magnetic cylinder post valve. Made by Sherwood Valve in the USA. This valve has a .750-16 UNF-2A inlet thread and a CGA 910 pin index outlet. The pressure relief device is CG-1 and is set at 3360 PSI. This valve is primarily used where non-magnetic valves are necessary - MRI applications. This valve is stamped to meet ASTM standard F2503-05 markings and meets level 3 tesla requirements. The valve is used in aluminum cylinders, primarily in the medical and homecare health fields. Shipped with PTFE o-ring installed. Please download our tech sheet for details regarding materials, replacement parts, and more.
